Discharge flow rate¹
5000 Ipm | 300 m³ per hour | 10600
scfh | 10.5 STPD | 9540 kg per day
O2 output pressure
20-100 psig | 1.4-6.9 barg
Operating temperature
0° F to 120° F | -18°C to 49° C
Power requirements (Site power source)
380/460/575 VAC+/- 10%, 50/60/60 Hz +/- 3%, 3-Phase, 150/120/90 Ampere
Power Requirements (Plant)
380/460/575 VAC, 50/60/60 Hz, 3-Phase, 100/75/60 FLA
Average power consumption
20 – 22 kW at 20 psig | 1.4 barg
22 – 25 kW at 55 psig | 3.8 barg
25 – 28 kW at 100 psig | 6.9 barg
Process outlet connection
2.5” Internal NPT Fitting
Unit Footprint Dimensions (nom.)
129”L x 49”W x 116”H | 328 cm L x 125 cm H x 295 cm H
Packaged Dimensions (nom.)
Contact PCI for packaged dimensions.
Unit Weight (nom.)
5,150 lbs | 2340 kg with five (6) compressors
Packaged Weight (nom.)
Contact PCI for packaged weights.
